Wire guide is one of the most important consumable parts for wire-cut EDM machines. It is made of a diamond sheet with a hole, ceramic insert, and stainless-steel case. The quality of the diamond, the accuracy of the hole, and the arc of the upper and lower chamfers of the diamond inside decide the processing quality and stability.
Our wire guides use Single-crystal diamond, which has superior wear resistance. To achieve high accuracy of the hole, we use Laser drilling machines to make the hole inside the diamond sheet, with the smallest hole 0.001mm.
Various EDM wire guides are available from us, such as for Sodick, Charmilles, Agie, Mitsubishi, Makino, Hitachi, Seibu, Chmer, Accutex, and SSG. we can also customize diamond wire guides according to the customer’s sample.
Charmilles EDM wire guide
Charmilles wire guide use diamond, hole sizes available from 0.075-0.33mm.
Two type of diamond - daimond sheet, and whole diamond intead of diamond sheet + ceramice instert.
For whole diamond type - both stainless house and ceramic house available
Following codes are most common size:
C101 200431021 0.07MM
C101 100431022 0.10MM
C101 200431114 0.15MM
C101 200431112 0.20MM
C101 100432511 0.25MM
C101 200432512 0.30MM
C101 135006537 0.33MM
C102 200431026 0.07MM
C102 100431027 0.10MM
C102 200431124 0.15MM
C102 200431122 0.20MM
C102 100430586 0.25MM
C102 200432814 0.30MM
C102 135006535 0.33MM
Sodick EDM diamond guide AQ series
It's same as Sodick orginal type.
Sodick code: 0206048, 118762A ID=0.11mm
Sodick code: 0205992, 118745A ID=0.155mm
Sodick code: 0206049, 118758A ID=0.16mm
Sodick code: 0206043, 118725 ID=0.205mm
Sodick code: 0206050, 118759A ID=0.21mm
Sodick code: 0205895, 118726 ID=0.255mm
Sodick code: 0206051, 118760A ID=0.26mm
Sodick code: 0205993, 118727 ID=0.31mm
